Trillium WSP™ Self-Primer Pumps

Trillium Flow Technologies
The Trillium Flow Technologies™ WSP™ self-primer pump is a rugged and dependable self-priming, trash pump that allows for a shim-less, tool-less impeller adjustment and ease of suction flap valve replacement. To increase the life of the WSP ™ range of pumps, we use the most durable wear and corrosion-resistant materials. Using advanced engineering techniques, the WSP™ range of pumps was developed to serve food and beverage processing, waste management, and material processing industries globally. Trillium WSP ™ Self-Primer pumps and parts are directly interchangeable with GRESCO®, Pioneer®, and Gorman-Rupp® pumps, offering flexibility in your applications.

All-Pumps is an exclusive industrial distributor of Trillium WSP™ Pumps in Australia. Get in touch with our team for complete options.

KNOW MORE ABOUT Trillium WSP™ Self-Primer Pumps

  • The WSP™ Self-Primer pump is a rugged and dependable self-priming, solids handling, trash pump.
  • The WSP™ Self-Primer pump is a rugged and dependable self-priming, solids handling, trash pump.
  • The WSP™ Self-Primer pump is a rugged and dependable self-priming, solids handling, trash pump.
  • The WSP™ Self-Primer pump is a rugged and dependable self-priming, solids handling, trash pump.
  • The WSP™ Self-Primer pump is a rugged and dependable self-priming, solids handling, trash pump.
  • The WSP™ Self-Primer pump is a rugged and dependable self-priming, solids handling, trash pump.
  • The WSP™ Self-Primer pump is a rugged and dependable self-priming, solids handling, trash pump.
Download Brochure

Design Features

Buzzsaw Wear Plate

  • With an aggressive saw tooth-shaped profile, it shears stringy materials as they pass through the pump, preventing clogs
  • Helps prevent the WSP™ self-primer pump from running in a state of partial clog
  • Allows the pump to run at higher overall efficiencies while lowering maintenance costs, extending valuable runtime.
  • Not available in WSP™ high-head models

Fill Port Cover & Clamp Bar Assembly

  • The recessed bolt-locking construction and anti-rotation design of the clamp bar assembly prevent accidental breach of the fill port cover, protecting the operator from scalding burns.

Available Options

Buzzsaw Wear Plate

  • 316 Stainless steel
  • Wear-resistant Alloy (400 BHN)

Casing

  • CD4MCu

Impeller and Seal Plate

  • High-chrome
  • CD4MCu

Mechanical Seal

  • Tungsten carbide faces

Spare parts

Custom mounting/baseplate

Key Specifications

  • Flow: 51-727 m³ /h
  • Head: 31-76 m
  • Solid size: up to 75 mm

Applications

  • Municipal and industrial wastewater
  • Automotive
  • Metal machining
  • Beef, pork, poultry processing
  • Production/manufacturing
  • Pulp and paper
  • Dewatering
  • Tanker truck unloading
  • Mining and minerals
  • Drilling mud recovery
  • Winery
  • Food and beverage

OUR RANGE OF AVAILABLE TRILLIUM WSP™ SELF-PRIMER PUMPS

WSP™ Self-Primer Pumps

SIZE FLOW (m3/h) HEAD (m) REPRIMING LIFT (m) SOLID SIZE (mm)
2” (50 mm) 51 31 7.3 38
3” (75 mm) 102 34 7.6 63.5
4” (100 mm) 166 36 7.6 75
6” (150 mm) 336 34 7.6 75
8” (200 mm) 595 33 7 75
10” (250 mm) 727 41 6.7 75

WSP™ High Head Self-Primer Pumps

SIZE FLOW (m3/h) HEAD (m) REPRIMING LIFT (m) SOLID SIZE (mm)
3” (75mm) 84 64 7 20
4” (100 mm) 148 58 5.1 28
6” (150 mm) 309 53 4.5 32

PRINCIPLE OF OPERATION

A trash pump has a rotating engine that powers a shaft that spins. Attached to the shaft is an impeller. As the impeller spins, the water is collected and pushed through the discharge line. Most trash pumps have an open or semi-open impeller design to allow solids such as rocks and twigs to pass through.
