Blacoh Spillstop Leak Containment

Blacoh pulsation dampener Logo

Blacoh’s SPILLSTOP™ leak containment technology prevents the terrible damage and health hazard that diaphragm failure may cause. A broken diaphragm leads to fluid leak through the air exhaust port, resulting in product wastage, material cleanup, and EPA reporting. The work of SPILLSTOP™ is to detect leaks during their early stages and prevent costly and hazardous spills by capturing leaked products while shutting down the failing pump. A warning alarm and backup pump switchover further ensure operators are aware of the leak while preventing prolonged system downtime and enormous production losses.

Design Advantages

  • Wide range of standard and ATEX certified models

  • Compatible with all AODD pumps with discharge sizes up to 4 inches

  • All Pneumatic, no hazardous electronics or batteries used

  • Bodies available in a full range of chemically resistant materials

  • US patented spill detector, containment, and prevention

  • Cost-effective, compact, high-quality materials, reliable

Available Options

  • Warning alarm

  • Automatic backup pump switchover options are available

  • Custom models

  • Pneumatic Whistle Alarm

  • Pneumatic-to-Electric Output

  • Additional Shutoff Valves

  • Custom materials

Key Specifications

  • Construction: Polypropylene, PVDF, Stainless Steel, Hastelloy C

  • Lid Materials: Noryl, Stainless Steel, PVDF, PTFE Coated Stainless Steel

  • Sizes: 19.05 mm – 25.4 mm Inlet



Applications

  • Food & beverages
  • Dairy
  • Oil, fat, sauce and mayonnaise
  • Brewing and beverages
  • Bakery and confectionery
  • Pharmaceutical
  • Chemical
  • Transportation
Talk to our Experts

PRINCIPLE OF OPERATION

SPILLSTOP™ is a fully pneumatic device attached to the exhaust of an AODD pump. It has a sealed internal receptacle that captures the process fluid that would have spilled through the exhaust when an AODD pump’s diaphragm fails. The failed pump automatically shuts down as the contained liquid raises a float switch. SPILLSTOP devices can also be equipped with an optional warning alarm whistle and backup pump switchover. With SPILLSTOP, AODD users can improve plant safety and prevent more extensive system damage.
